Standard equipment routing
The 1.8 m length supports flexible routing between the power source and equipment.
C20 to C21 Red 1,8 m, 20a/250v, 12/3 SJT Power Cord
IEC 60320 jumper cord · MK4530
1.8 m red C20 to C21 equipment connection
This red power cord connects an IEC C19 outlet on a PDU or UPS to equipment fitted with an IEC C22 inlet. The 1.8 m length provides a defined cable route for professional installations.
ConnectionC20 plug at the power source; C21 connector at the equipment. This is a standard non-locking cord.
Key specifications
20 A / 250 V
Use only within the rating of the complete product and every connected outlet, inlet and device.
12/3 SJT
North American flexible cord construction. Use only within the product-specific rating and approvals.
Typical applications
Very-hot-condition equipment
- Equipment fitted with an IEC C22 inlet
- High-temperature professional installations
- Applications verified against the complete-cord rating
Download the product drawing
Use the product drawing to check dimensions, construction and other product-specific information for MK4530.
Download drawing (PDF)Hot-condition interface. The connector type alone does not define the usable temperature of the complete cord; verify the SKU specification.
Need another length, color or quantity?
MK Cable can help you select a stock alternative or prepare a quotation for a project requirement.
Additional parameters
| Category: | C20 to C21 Power Cords |
|---|---|
| Length: | 1,8 m |
| Color: | Red |
| Conductor Size: | 12 AWG |
| Amperage: | 20 Amp |
| Jacket: | SJT |
| Certification: | UL, cUL |
| Connector: | C21 |
| Plug: | C20 |
| Voltage: | 250 V |
| Model no.: | CZC2012C2172R |
